Model | Diameter (mm) | Diameter (um) | Weight（kg/m） | Effective case depth（mm） |
ADS3 | 3 | -2~-8 | 0.06 | >0.8 |
ADS4 | 4 | -4~-12 | 0.10 | |
ADS5 | 5 | 0.16 | ||
ADS6 | 6 | 0.23 | ||
ADS8 | 8 | -5~-14 | 0.40 | |
ADS10 | 10 | 0.62 | >1.0 | |
ADS12 | 12 | -6~-17 | 0.89 | |
ADS13 | 13 | 1.04 | ||
ADS16 | 16 | 1.58 | >1.5 | |
ADS20 | 20 | -7~-20 | 2.47 | |
ADS25 | 25 | 3.85 | >2 | |
ADS30 | 30 | 5.55 | ||
ADS35 | 35 | -9~-25 | 7.55 | >3 |
ADS40 | 40 | 9.87 | ||
ADS50 | 50 | 15.4 |
|  |
| |
